| Dimensions | 276 mm (L) x 220 mm (W) x 91 mm (H) |
| Weight | 1.3 kg |
| Operation Temperature | 15 – 35 ° Celcius |
| Communication Ports | USB 4 ports, LAN port, USB OTG port |
| Power Supply | DC 12V/5A, AC/DC Adaptor, (AA battery) DC 1.5V X 4ea. Input 100-240V ~ 50/60Hz, 1.8A. Output DC 12V/5A |
| Motor | Stepper Linear Actuator (5V, 0.34A) |
| Data Output | 7” touch color LCD |
| Storage Temperature | Temperature -20 ~ 50°C, Humidity Max. 70% |
| Test Result Storage | Patient test results (1,000) / System check results (500) Standard material (control) test results (1,000) |
